LM24-3008NB NPN NC Flush Type Position Sensor M24 Inductive Proximity Switch

Ask Lasest Price
Model Number :	LM24-3008NB
Brand Name :	Kampa
Supply Ability :	100000 Piece/Pieces per Month
Price :	$4.00/Pieces 100-499 Pieces

Add to Cart

Product Details
Company Profile

LM24-3008NB NPN NC Flush Type Position Sensor M24 Inductive Proximity Switch

Product Description

Sensing Surface Type:	Non-flush Type	Flush Type
Detection Distance:	10mm±10%	8mm±10%
Detection Object:	metal
Frequency:	DC: 200Hz AC: 25Hz
Voltage Supply:	10~30VDC, 90~250VAC
Saturation Voltage (DC 3-wire):	DC <3V; AC <10V
Current Consumption:	DC <15mA; AC <10mA
Ambient Temperature:	-25 ~ +75℃
Insulation Resistance:	≥50MΩ
IP Grade:	IP67
Material:	brass nickel-plated case, PBT detection surface, PVC cable

Specification

Model: LM24-3008-
LM: inductance type proximity sensor			M24: diameter	30: working voltage 6-36V	10: detection distance

Output form:					Non-flush type:	Flush-type:
DC6-36V	NPN	NO	LM24-3010NA	LM24-3008NA
				NC	LM24-3010NB	LM24-3008NB
				NO+NC	LM24-3010NC	LM24-3008NC
		PNP	NO	LM24-3010PA	LM24-3008PA
				NC	LM24-3010PB	LM24-3008PB
				NO+NC	LM24-3010PC	LM24-3008PC
		2-wire	NO	LM24-3010LA	LM24-3008LA
		2-wire		NC	LM24-3010PB	LM24-3008PB
AC90-250V	SCR	NO	LM24-2010A	LM24-2008A
				NC	LM24-2010B	LM24-2008B
				NO+NC	LM24-2010C	LM24-2008C
		Relay output
